HolteK small package Flash MCU series adds HT68F001 members, characterized by low cost, low operating voltage, low power consumption and high accuracy Timer. Among them, the minimum operating voltage can reach 1.8V, the working current is 3μA @ 3V and the accuracy of Timer is ± 1 %, which makes this product very suitable for product applications with accurate timing and simple control, such as battery product timer, small household appliance timer and industrial control. The battery product timer products include : water filter filter, electric toothbrush, LED lamp, flashlight, clock alarm clock, fish tank automatic feeder, aromatic machine and toys and other consumer products ; small household appliances timer products include : toaster, charger, electric fan and electric cakes and other small household appliances ; industrial control products include : delay switch, anti-theft detection and other On / Off time control products.
The operating voltage of HT68F001 is 1.8V ~ 5.5V, and the system resources are 0.5K × 12 Flash Memory, 16 × 8 RAM, 8-bit Timer and Time Base. Oscillator LIRC ( 32kHz ) is a high-precision oscillator circuit that provides MCU system frequency, so that the entire product can work at a more accurate and lower voltage and current, and the package provides 8-pin SOP.
