General Description

The SSW22028 is a Bluetooth dual-mode 5.1 and Wi-Fi 802.11n module. The module integrates hardware and software resources needed to complete Wi-Fi and Bluetooth applications, supports AP and STA dual role connections, and supports both classic and low-power Bluetooth connections.

The SSW22028 has a wealth of peripherals, such as PWM, I2C, UART, SPI, SDIO and IRDA. You can download and burn the program directly through UART. Up to six channels of 32-bit high-speed PWM output use the chip ideal for high quality LED control. Each 2 PWM can be configured for phasecontrolled differential mode to support motor and lamp strip drives.
The SSW22028 has built-in EFUSE and supports OTP reading and writing within Flash, which can be used to provide unique serial numbers, code encryption, and secure debugging interfaces. Internal integration of true random number generator and security module, ensure the security of communication and fast
The SSW22028 internally integrates priority-based Wi-Fi and Bluetooth coexisting control module to realize real-time priority and dispatch.

The SSW22028 supports external PA and LNA extensions by providing an indication of the transceiver status of the current transceiver. authentication and network connection.

The SSW22028 supports low-power sleep mode, and the MCU can enter the sleep state and reach the microamp level of sleep current. The SSW22028 supports deep sleep mode, which can run 32 bit clock at several microampals of current and can be awakened by this clock or by any GPIO.

The SSW22028 is a compact WIFI module that supports 802.11b/g/n single-stream, low-power application processor. It is a low cost serial WIFI module that supports UART-WIFI-ethernet data transmission.

Application

IOT (internet of things)
Network Consumer Device
 Metering
 Building Automation
 Home Automation
 Smart Home Gateway
 Smart Lighting
 Smart Plugs and Lights
 Baby Monitors
 Mesh Network
 Sensor Network
 Industry Control

Feature

 802.11 b/g/n
 Integrated classic Bluetooth and low power BLE system
 Bluetooth and Wi-Fi share antennas and transceiver circuits
 Internal priority-based scheduling logic ensures the stability of Bluetooth and Wi-Fi dual connections and the efficient sharing of air resources
 802.11n (2.4 GHz) up to 150Mbps
 Support STA and AP
 AT Set, cloud server, application
 Network protocol: IPv4, TCP/UDP/HTTP/FTP
 256 KB internal RAM
 2 MB internal Flash
 256 Byte ~ 2K Byte OTP
 Wi-Fi Protected Access (WPA)/WPA2/ WPA2 Enterprise/Wireless Network Connection Accepted Settings (WPS)
 Six - way high - speed 10 - bit multi - channel ADC, and support internal filtering to 16 - bit
 Compliant with RoHS FCC,CE
